Valiant Ultra 300

Multifunctional robust and reliable treadmill
Ultra large treadmill with 300×200 cm belt surface for various applications. By choosing accessories and options the treadmill can be configured to your specific application.

The available configuration is very complete:

  • Speed: 0 – 40 km/h / Start-up speed and speed steps: 0,1 km/h
  • Positive elevation: 0 – 25% / Negative elevation: -25 – 0 %
  • Safety: fallstop, emergency stop button and safety lanyard
  • Display: programmable 7″ Control Unit
  • Handrails: adjustable and removable
  • Connectivity: to be controlled by external ECG- and Pulmonary devices and by a Lode Software Network (LEM or LCRM)

The functionality of the Lode’s Valiant Ultra 300 treadmill can be enhanced considerably by using it with the Lode Ergometry Manager Software (#955900).

  • Speed: 0.1 – 40 km
  • Speed adjustment step: 0 km
  • Positive elevation: 25 %
  • Elevation adjustment steps: 0 %
  • Optional negative elevation: -25 %
  • Speed accuracy <2 km: ± 0.1 km
  • Speed accuracy >2 km: ± 5 %
  • Accuracy inclination: 0,3 %
  • Maximum user weight: 225 kg
  • Screen resolution: 800x 400 pixels
  • Walking surface length: 300 cm
  • Walking surface width: 200 cm
  • Step up height: 35 cm
  • Size: 325 x 296 x 260 cm (LxWxH – no elevation)
  • Size: 325 x 296 x 290 cm (LxWxH – max elevation)
  • Product weight: 1000 kg
  • Maximum rated power input: 8000 VA power input
  • Maximum motor power: 8 kWPower cord 3L+N+PE
    3 x 400 V
Contact Sales Representative
Brochure Product Manual Dimensions Guide

Valiant Ultra 300 Highlights

  • Compatible with ECG and pulmonary devices. The Valiant Ultra 300 treadmill can be controlled by all external stress test ECG and ergospirometry devices through the RS232 or USB port.
  • Extreme speed up to 40 km/h. The treadmill standard has a speed from 0 – 40 km/h
  • Various handrails available. Handrails are optional available, making the Valiant Ultra 450 treadmill suitable for your specific stress test setting.
  • Extreme performance option available. Various options like high speed; negative elevation; fallstop make this treadmill the gold standard for top athletes.
  • Unique ultra large dimension. The extreme dimensions of this treadmill provides the possibility to use for various applications and sports medical settings.
  • Valiant Ultra 300 is designed to withstand continuous heavy use by subjects in most weights and sizes. With standard safety lanyard to enable automatic emergency stop.
  • Various interface protocols guarantee perfect communication with all commonly known stress ECG and spirometry equipment and the speed of the treadmill can be adjusted in the smallest steps of only 0.1 km/h. The positive elevation of the treadmill is 25%. This slope is enough for protocols used for the normal and healthy test subjects. Other elevations are available on request.
  • Service friendly belt treadmill because of the unique impregnated belt, no belt-greasing and no bearing-greasing are required. The belt is centered automatically without additional adjustment. The only annual maintenance that has to be done is checking the running and electrical parts and the velocity calibration of the treadmill.
  • Closed loop motor control enables, full great at zero speed, load independent speed, angle independent speed and rigid speed control at all speeds, typically at interest when using steep angles, low speeds and/or high Test Subject weight.
  • Optional: The treadmill can be extended with a stable and reliable blood pressure module and SpO2 measurement.
